Turn your delicate pastries, decorated cakes, and patisserie creations into high-volume grab-and-go impulse purchases. The Cake High-Back Open Cabinet combines an expansive, high-capacity vertical footprint with barrier-free, open-front accessibility. Engineered specifically for bakeries, cafes, delis, and supermarkets, this multideck merchandiser uses gentle, humidity-balanced cooling to keep sponges moist and icings pristine while making selection effortless for busy shoppers.
The heavy-duty, adjustable shelving tiers can be set flat or tilted to highlight artisan cakes, tarts, and boxed treats under high-luminance, low-heat internal LED canopy lighting. Built with injected polyurethane insulated wall construction and a floor-level stainless steel bumper rail to deflect shopping cart impacts, the unit also includes an integrated manual night curtain to dramatically reduce energy costs after hours.
| M2 | Units | 6ft | 8ft | 12ft | HEAD PIECE |
|---|---|---|---|---|---|
| Length | mm | 1875 | 2500 | 3750 | T.R.2025 |
| Height | mm | 2040 | 2040 | 2040 | 2040 |
| Depth | mm | 950 / 1130 | 950 / 1130 | 950 / 1130 | 950 / 1130 |
| Thickness of end | mm | 35 max 50 | 35 max 50 | 35 max 50 | 35 max 50 |
| Gross Volume | m³ | 1.57 / 1.67 | 2.09 / 2.25 | 3.15 / 3.38 | 1.57 / 1.67 |
| Total Display area | m² | 3.24 / 3.58 | 4.33 / 4.78 | 6.49 / 7.16 | 3.24 / 3.58 |
| Evaporator fans | nr.x watt | 2 x 10 | 4 x 10 | 6 x 10 | 2 x 10 |
| Lighting | nr.x watt | 2 x 36 | 4 x 36 | 6 x 36 | 2 x 36 |
| Nr. Defrost in 24h | nr.x 24h | 3/24h ~ 70 min def. +10˚C | 3/24h ~ 70 min def. +10˚C | 3/24h ~ 70 min def. +10˚C | 3/24h ~ 70 min def. +10˚C |
| Refrigeration Capacity (300 front at -7˚C) | watt | 2213 / 2353 | 2985 / 3183 | 4415 / 4699 | 2213 / 2353 |
| Refrigeration Capacity (440 front at -7˚C) | watt | 1992 / 2118 | 2687 / 2865 | 3974 / 4230 | 1992 / 2118 |
| Refrigeration Capacity (540 front at -7˚C) | watt | 1793 / 1907 | 2419 / 2579 | 3577 / 3807 | 1793 / 1907 |
| Rating Power | watt | 1150 | 1380 | 1840 | 460 |
| Daily Electrical Consumption | KWH/24 | 2.6 | 3.9 | 5.3 | 2.6 |
Q: Will the open front design cause fresh cakes and pastries to dry out?
A: No. The refrigeration system is specifically engineered for confectionery products, using balanced coil temperatures and gentle, low-velocity airflow rather than aggressive dry cooling. This maintains sufficient moisture levels within the air curtain to prevent sponge cakes, mousses, and delicate buttercreams from crusting or drying out.
Q: Can the shelves be angled to display flat bakery trays and boxed cakes better?
A: Yes. The heavy-duty shelf brackets feature adjustable tilt positions. Angling the shelves downward pairs with the front acrylic risers to create a cascading stadium view, ensuring customers on any aisle approach have a clear, direct view of your baked items.
Q: How does the night curtain help manage operating costs?
A: Pulling down the integrated manual night blind when your store closes creates a thermal barrier over the open front. This keeps chilled air sealed inside, significantly lowers electrical draw overnight, and prevents unnecessary compressor cycling when customer foot traffic is zero.
Designed to maximize revenue per square meter of retail floor space, this vertical open-front cake cabinet showcases multi-layered dessert displays at prime customer eye level. Unlike harsh refrigeration systems that dry out delicate confectioneries, its precision air distribution delivers gentle, uniform airflow across every tier to protect textures and appearances.
Breakthrough technology replaces a conventional thermostat with an advanced electronic energy management system to cool quicker and maintain a more consistent temperature, while saving precious electricity.
By combining EMD control with ECM fans, electronic expansion valves and high-performance coils, we are able to further reduce energy consumption while improving cooling performance.
Our innovative swift swop™ technology enables easy replacement of the refrigeration deck without unpacking the contents of the fridge and without any skilled labour.
