Transform the high-traffic ends of your supermarket aisles into high-converting impulse sales zones. The Crown End Display Case is a heavy-duty, semi-circular or wrap-around merchandising unit engineered to cap off island freezer and chiller lineups seamlessly. By offering wide, panoramic viewing angles and barrier-free product access, this unit turns dead aisle-end floor space into a dynamic visual driver for seasonal promos, frozen meal features, or chilled beverages.
Engineered with high-performance uniform air distribution, it maintains steady target temperatures across its expansive horizontal or tiered display decks. Heavy-density injected polyurethane foam core walls provide superior thermal insulation, while wrap-around stainless steel or heavy-duty PVC bumper rails shield the frame from high-impact shopping trolley collisions. Available in self-contained plug-in setups or remote multiplex configurations, the Crown End cabinet is the ultimate anchor for modern retail aisle layouts.
| Units | HEAD PIECE | |
|---|---|---|
| Length | mm | TEST.2200 |
| Width | mm | 995 |
| Height (Front Glass) | mm | 400 |
| Total Height | mm | 890 |
| Thickness of end | mm | 60 |
| Gross Volume | m³ | 703 |
| Total Display area | m² | 2.57 |
| Evaporator fans | nr.x watt | 2 x 10 |
| Antimist heater | watt | 234(L) 122(M) |
| Defrost Heater | nr.x watt | 1 x 1000(L) 1 x 315(M) |
| Nr. Defrost in 24h | nr.x 24h | 3/24h ~ 45 min def. +12˚C |
| LOW TEMP | ||
| Orifice | nr. | TES2 or.02 |
| Refrigeration Capacity (-35˚C) | watt | 840 |
| Rating Power | watt | 1200 |
| Daily electrical consumption | KWH/24 | 10.8 |
| MEDIUM TEMP | ||
| Orifice | nr. | TES2 or.00 |
| Refrigeration Capacity (-10˚C) | watt | 550 |
| Rating Power | watt | 1150 |
| Daily electrical consumption | KWH/24 | 6.2 |
Q: What is the primary merchandising purpose of a “Crown End” cabinet?
A: A Crown End cabinet sits at the end of dual-island freezer or chiller rows. Instead of leaving a flat, unbranded terminal wall, the Crown End provides rounded, multi-directional product display space, capturing shoppers turning between aisles and significantly increasing high-margin impulse sales.
Q: Can the Crown End be matched seamlessly to existing island freezer lines?
A: Yes. Crown End units are specifically engineered to match the profile heights, exterior finishes, bumper rail alignments, and temperature specifications of standard supermarket island cases (such as Jumbo Islands or Timor series), creating a clean, cohesive retail appearance.
Q: Does the unit prevent condensation from forming along the glass borders?
A: Yes. Closed glass-top models feature integrated low-wattage frame anti-mist heaters and low-emissivity glass to eliminate condensation and misting, keeping promotional items fully visible even in humid retail store environments.
The Just Refrigeration Crown End display cabinet is designed specifically for high-volume grocery environments, hypermarkets, and wholesale retail stores looking to maximize revenue per square meter. Positioned at the head of standard back-to-back island or multideck runs, its curved or contoured panoramic profile draws shopper attention from multiple aisle directions simultaneously.
Breakthrough technology replaces a conventional thermostat with an advanced electronic energy management system to cool quicker and maintain a more consistent temperature, while saving precious electricity.
By combining EMD control with ECM fans, electronic expansion valves and high-performance coils, we are able to further reduce energy consumption while improving cooling performance.
Our innovative swift swop™ technology enables easy replacement of the refrigeration deck without unpacking the contents of the fridge and without any skilled labour.
Our innovative swift swop™ technology enables easy replacement of the refrigeration deck without unpacking the contents of the fridge and without any skilled labour.
